Unique Design:
1. Display Size: 1.5 HD TFT Screen.
2. Imaging sensor: AR0330 effective 3 megapixels, and 6-GB lens
3.Dual camera recording
5. Support the seamless cycled recording function
7. Video Resolution: HD1080P, FHD720P Adjustable
8. H.264 compression mode, and MOV format
9. Video Frame Rate: 30FPS@1080p; 60FPS@720p
11. Video Protection, prevent overwrite important
12.Hidden installation without suck cup bracket
1342.Support GPS track function(optional)
14.Support ADAS, LDWS,time-lapse photography,fatigued driving warning,dippped headlight warning
16. Built-in G-sensor
17. Support AV-OUT
18. Support HDMI
19. Support Movement Detection
20. Support Audio On/Off while Video Recording
21. TF Card, Maximum 32GB
22. Battery: 3.7V, 300MAH Li-polymer Battery
23. Adapter: Mini USB 5PIN Port and DC 5V
Hardware Specification:
| Item | car black box |
| Main control chip | NT96655 |
| Imaging sensor | AR0330 effective 3 megapixels, and 6-GB lens |
| Angle of View | 170° |
| Screen Size | 1.5 inch |
| Cycled Recording | Support the seamless cycled recording function |
| Video Resolution | HD1080P and HD720P |
| Video Frames | 30FPS@HD1080P and 60FPS@HD720P |
| Video Compression Format | H.264 compression mode, and MOV format |
| Size of Recording File | 90MB/MIN@1080P |
| Anti-shake | Provide the anti-shake function for electronic video |
| Mobile Detection | Supported |
| GPS Track | Supported |
| AV OUT | Supported |
| PC Camera | Supported |
| Collision Sensing | Sensitivity-adjustable triaxial three-dimensional collision detection |
| Fast Forward and Fast Backward | Adjust the volume in the playback mode |
| Language | Chinese, Traditional Chinese, English, Spanish, Russian, Portuguese, German, Italian, Japanese, and French |
| Storage Mode | TF card with a maximum capacity of 32 GB |
| Photo Format | JPG |
| Audio Recording | Support selective audio/video recording and synchronous audio/video recording |
| External Power Supply | Mini USB 5PIN interface, and USB5V |
| Built-in Power Supply | No |
| Operating Current | 400MA |
| Quiescent Current | 20 mA |
| Storage Temperature | -20 to 70°C |
| Operating Temperature | -10 to 60°C |
| Operating Humidity | 15% to 65% (RH) |
| Operating System | Support the WIN2000/XP/WIN7 |
| Dimensions | 72 x 52 x 43 mm (excluding the bracket) |
| Shell Material | ABS engineering plastic |
| Surface Technique | Oil injection |
Accessories:
– Car Charger
– 360 Degree Rotatable DVR Mounting Frame
– 3M Sticker(*2)
– User manual.
– Optional Accessory: Suction Mounting Stand
