Big eyes Camera Full HD 1920*1080P 30FPS&2.7″ LCD+140 Wide Angle bulit in 4GB car driving dvr
Spec
1. bulit in 4GB memory and Built-in 5.0 mega pixels high resolution camera
2.14degrees wide-angle lens
3.support TF card up to 32G (not included)
4.HD/VGA switching
5.Support HDMI
6.Aragtida habeenkii
7.2.7 inches display screen
8.Built-in lithium battery.
9.Built-in microphone
10.Auto start and record after the vehicle is started
11.Start recording automatically when turn on the recorder
12.Video recording function
13.Digital camera function
14.Video playing function
15.Recording frame rate 30 fps
16.AVI video format
17.Supports real time playback
18.Recording mode: automatic records when car power is on
19.Cycling records automatically, over-write if memory is full
20.USB port: connect to computer for upgrade and backup
21.Car cigarette lighter power supply, easy installation
22.After car power is off, Li-ion battery will provide 10 seconds power to prevent video files loosing
23.Control buttons: Record, Menu, Play, Reset
24.Power Supplied by Car Charger
| Visual angle | Wide angle 140° |
| Pixel of lens | 5.0 mega pixels CMOS |
| Rotation angle | NIL |
| Picture format | JPEG |
| Picture pixel | Mzx 4000*3000 |
| Xallinta muuqaalka | 1280*720P |
| Qaab muuqaal ah | AVI |
| Video frame number | 30fps |
| Store temperature | -20-60°C |
| Operate temperature | -10-60°C |
| Operate humidity | 15-65%RH |
| Charging current | Max450MA |
| Charging time | ≥3H |
| Type of memory card | ≥TF-Class4 |
| Capacity of memory card | 2G-32GB |
| Capacity of battery | 800-1500MA |
| Power consumption | 300MA-600MA |
| Web camera | Support |
| USB Interface | USB2.0 |
| USB flash disk function | Support |
| Infrared night vision | Support |
| Hdmi | Support |
| G-SENSOR | Support |
| Size of display screens | 2.7 Inch |
| Player software | Media Player/KM Player |
| Audio recording | Synchronous sound and video recording |
| Recording area | 40 Square meter |
| Luuqad | Support multinational languages |
Menu Settings:
1. The main menu:
In standby mode short click the menu button, popup function menu, click again to switch to the system menu Settings. In the menu press turn key to button up/down the direction key to turn on/next turn operation, location to set menu item, click OK button to enter, positioning to need to set up parameters, press OK key set up complete.
(1)Video function menu :
1. Resolution 2. Cycle video 3. Exposure 4. 5. Video motion detection voice 6. Date record
(2)System Settings menu item :
1. The date/time 2. Automatic off 3. Automatic screen-off 4. Prompt 5. Light lamp set 6. Languages(English/Korean/west/German/Italian/method/day/Russia/simplified Chinese/traditional Chinese, ten languages) 7. Television output 8.frequency 9. Card choose 10.record covertly 11.format 12. The default value 13. G_SENSOR 14. Version
(3)Taking pictures function menu :
In the photo mode, short press the menu button into taking pictures photos function menu.
1. Resolution 2. White balance 3. Exposure compensation 4. Prevent hand shock 5. Date label
Playback function menu group
(4)In display mode, short press the menu button into the display function menu.
1. Delete 2. protection3.slide play
other note:
1. This product with high technology content optical imaging device, do not recommend long placed in low temperature condition, temperature or boot from the water vapor could have harmful effect on the machine
2. Operation didn’t respond, may be because of wrong operation into the record covertly state or software problem, reset can restore
3. Trigger record covertly if not remove in time, the machine will always video until the batteries run out of power, so please use caution and remove in time state
4. Please ensure that before video camera not smudginess, such as a finger print will directly affect the shooting effect, will have been brain washed, and ran the feeling of coke
5. The machine bring high capacity lithium polymer battery, connect the computer and car charger are charging, charging process red light long bright, full charge after go out
Maxaa noo doora?
1. Dhammaan alaabooyinka si adag ayaa loogu hubiyay tayada guriga ka hor inta aan la xidhin.2. Waxaan nahay warshad soo saarta CAR DVR oo loogu talagalay 5 sanado leh tayo wanaagsan iyo adeeg sare.
3. Waxaan nahay alaab-qeybiye OEM ah oo badan oo caan ah oo Car DVR ah.
4. 100% Kormeerka QC ka hor inta aan la rarin, 12 Imtixaanka gabowga saacadaha ee alaabta unug kasta.
5. Waxaan bixinaa nashqado la habeeyey oo bilaash ah iyadoo loo eegayo shuruudahaaga.
6. Waan furi karnaa caaryadaada haddii aad u baahato.
7. 12 damaanad tayada bilaha.
Tusaalooyinka & Rarista
1. Tusaalaha iyo dalabka yar ayaa lagu keeni doonaa gudaha 2-3 maalmaha shaqada kadib helitaanka lacag bixinta iyo faahfaahinta dalabka ayaa la xaqiijiyay.2. Dhammaan alaabooyinka si fiican ayaa loo soo buuxiyay ka hor inta aan la dhoofin,waxaanu alaabta ku diri karnaa hawada,UPS,DHL,FEDEX,EMS,TNT iwm.
3.Si aad u dalbato in ka badan 500pcs ama dalab la habeeyey, wakhtiga hogaaminta ayaa noqon doona 4-6 usbuuc kadib helitaanka lacag bixinta. Fadlan la xidhiidh iibkayaga si aad u hubiso alaabta hadda jirta.
Free Enquiry for Full HD 1080p bulit in 4GB car driving dvr
1 dib u eegis loogu talagalay Full HD 1080p bulit in 4GB car driving dvr
Ku dar dib u eegis
Qaar ka mid ah su'aalaha inta badan la weydiiyo Shiinaha Baabuurka DVR
Q. Waa maxay dammaanadda CAR DVR?
A. Loogu talagalay CAR DVR, waxaan leenahay 12 damaanad bilo.Q. Waa maxay habka lacag bixinta ?
A. T/T . PAYPAL , Western Union , L/C dhamaantood waa la heli karaa. dhib kuma jirto .Q. Sidee ku saabsan tayada ?
A. 100% Kormeerka QC ka hor inta aan la rarin, 24 Imtixaanka gabowga saacadaha alaabta unug kasta oo qolkayaga tijaabada ah . haddii la helo dhibaato tayo leh . Hengye waxa uu ballan qaaday in uu mid cusub u beddelayo macaamiisheena.Q. Intee ayay qaadanaysaa in la soo raro dalabkayga?
A. Ilaa iyo inta kaydka la heli karo, maraakiibta alaabta gudaha 3 maalmaha shaqada ee muunad iyo 7-15 maalmaha shaqada ee amarka rasmiga ah marka aan helnay xaqiijinta amarka cusub.Q. Yaa bixin doona xamuulka alaabta dayactirka?
A. Labada dhinacba waxay wadaagi doonaan kala badh xamuulka. Iibsaduhu wuxuu qaadi doonaa xamuulka inuu dib ugu celiyo GHY, iyo GHY waxay qaadi doontaa cabsida ah inay dib ugu celiso iibsadaha. GHY waxa ay soo jeedinaysaa in lagu soo celiyo si wadajir ah shayga soo socda ee tirada badan.Q. Waa imisa qiimaha rarida?
A. Waxay ku xiran tahay tirada wanaagsan, habka dhoofinta iyo meesha loo socdo. Waxaan u diri doonaa alaabta gudaha 3-5 maalmo shaqo ka dib markii la xaqiijiyo lacag bixinta buuxda. Haddii lacag-bixinta la waayo, Dalabkaaga si toos ah ayaa loo xidhi doonaa. DHL/UPS/FedEx Express waxay caadi ahaan qaadataa 3-5 maalmaha shaqada ee loo socdo. Waxayna ku saabsan tahay 5-8 maalmaha shaqada EMS ama TNT.Q: Ma haysaa wax adeeg iib ah kadib?
A:Haa! Waxaan haynaa adeeg xirfad leh oo iibka kadib ahQ. Sida loo dalbado?
Haddii aad qabto wax dhibaato farsamo ama su'aalo ah oo ku saabsan alaabta, ku soo dhawoow inaad la xidhiidho Waaxda Taageerada Farsamada. ama iibkeena si toos ah.
1. Noogu soo dir emailka qaabka, qaabka beam iyo tirada ama noo soo dir su'aal https://www.chinacarblackbox.com/ , macluumaadka rafiiqa, habka dhoofinta iyo shuruudaha lacag bixinta.Q. Waa maxay Soo celintaada iyo dammaanaddaada?
↓
2. qaansheeg la sameeyay oo laguu soo diray.
↓
3. Bixinta Dhamaystiran ka dib markii la xaqiijiyo PI.
↓
4. Xaqiiji lacag bixinta oo habayso wax soo saarka.
↓
5. Alaab u dir 2-15 maalmo(marka loo eego heerka kaydinta).
↓
6. Dir lambarka dabagalka(hawo) ama B/L(xagga badda).
↓
7. Alaabta la geeyey, soo dhawoow dib u dalbo!
1.Dhammaan alaabta waa la baaraa ka hor inta aan la rarin, marka haddii aadan ku qanacsanayn iibsashada, waxaad ku beddeshaa alaabta hal usbuuc gudaheed waana inaad nala soo xidhiidho 24 saacadaha helitaanka iibsashadaada.
2.Kharashka dhoofinta iyo maaraynta lama soo celin karo macmiilkuna waa inuu mas'uul ka noqdaa dhammaan kharashyada soo celinta iyo soo celinta.
3.Dhammaan alaabada soo celinta waa inay ahaadaan shuruudihii asalka ahaa, oo ay ku jiraan sanduuqa iyo qalabyada. Nimanka cilladaysan lama dammaanad qaadayo, sida jabay, xagashada iyo wixi la mida.
4.Wax kasta oo shay ah fadlan u soo dir EMS ama boostada deegaankaaga marka dib loo soo celiyo.
5. Qodobka dammaanadda
a. Guddaha 7 maalmo iibsi, haddii ay jirto wax dhibaato ah oo Baabuurka DVR ah, waa inaan kuu bedelnaa, laakiin waa inaad ilaaliso baakooyinka iyo Baabuurka DVR mid qumman.
b.Dammaanadda hal sano ka dib iibka, dammaanadda batteriga muddo saddex bilood ah.
c.Adeegga dammaanadda ayaa wax ku ool u ah isticmaalka caadiga ah oo keliya.
d.Dhammaan waxyeelada (Burburka dusha sare, ka jeex dhejiska, isticmaalka aan habboonayn) ama waayi kaadhkan, Ma dammaanad qaadi karno adeegga.
Aqoonta ay tahay inaad ka ogaato Baabuurka DVR
Haddii marka aad isticmaalayso kamarada, dhibaato yar soo foodsaarto, fadlan u shaqee sida soo socota marka hore.
1)Ma dhici karto duubis muuqaal caadi ah- beddel kaarka TF
- beddelo xallinta, loox halkii ilbiriqsi.
- geli kaadhka xusuusta ee awoodda weyn.
- hubi in kaadhka si sax ah loo rakibay (inta lagu guda jiro habka rakibo, waa inaad maqashaa dhawaaq riixaya).
- ka tirtir faylasha aan loo baahnayn kaadhka xusuusta si aad u sii daayso meel bannaan.
2)Fiidiyowgu ma cadda
- hubi in muraayada kamarada waa nadiif.
- ka tirtir boodhka iyo wasakhda muraayadda, ka dibna toogto.
3)Qalabka si caadi ah loogu shaqeeyo, laakiin furuhu ma shaqeeyo
- riix badhanka dib u dajinta si aad u bilawdo mishiinka.
Q: Sida loo bilaabo?
A: Waxaa jira 3 siyaabo:Q: Waa maxay nooca wadista kaaamka dash-ka ee ugu habboon?
Waxay si toos ah u bilaabi doontaa duubista, marka baabuurkaagu bilaabo oo uma baahnid inaad wax gacanta ku qabato. (Intaa ka hor, Hubi in kaarka TF uu ku dhex jiro oo dabaylaha baabuurku si fiican ugu xidhan yahay.)
Haddii batarigu aanu faaruqin, kaliya waxaad u baahan tahay inaad riixdo badhanka korontada.
Ku xidh fiilada USB adigoo isticmaalaya fiilada korontada ama bangiga korontada. (5V1A oo leh deked USB ah)
A: Dhammaan baabuur wadista ka imanaya safarada gaagaaban, safar shaqo iyo fasax. Baabuurka DVR ayaa duubaya dhammaan.Q: Waa maxay sababta dvr-kaygu aanu duubi karin?
Haddii shaqadaadu kaaga baahan tahay inaad baabuur wado markaa waa inaad hubaal leedahay kamarad dash ah oo la qaadan karo DVR. Si daacad ah, Qof kasta oo wada wuxuu u baahan yahay ilaalinta markhaatiga ee baabuurka DVR uu bixiyo.
A : Pls iska hubi kaadhka xusuusta marka hore, Haddii kaadhka gudaha ku jiro uu leeyahay muuqaal ama sawir kale oo dvr ah, laguma akhriyi karo qalabka dvr baabuurkaaga, waa inaad marka hore qaabaysaa kaadhkaaga TF, Si fiican u isticmaal kaarka TF madhan aaladdaada dvr marka aad isticmaasho marka ugu horeysa.
Q : Waa maxay sababta muuqaalka dvr-kaygu uu si toos ah u damiyo marka uu gaadhiga wado ?
A : Sida caadiga ah qalabka dvr wuxuu ku jiraa heerka heeganka haddii aadan ku samaynin wax ka badan wax qalliin ah 1 daqiiqo, laakiin sidoo kale way sii socotaa duubista.
Q: Waxa ay ka dhigan tahay marka kamarada dashku ay wareegeyso ama siddo?
A: Loop ama looping waa habka muhiimka ah ee u oggolaanaya DVR baabuurka inuu si joogto ah u duubo muqaal (saacad ka dib) isla kaadhka xusuusta. Sida kamaradu u duubto goobta "loop" ama "cycle"., waxay abuureysaa faylal fiidiyoow ah ama qaybo ka mid ah 2, 5 ama 10 dhererka daqiiqo. Faylashan waa la duubay oo si xidhiidh ah ayaa loo kaydiyaa (midba midka kale ka dib) ilaa kaadhka xusuusta. Marka kamaradu buuxiso kaadhka xusuusta (oo leh faylal badan), waxay tirtiri doontaa qaybta fiidyaha ee ugu horeysa / fayl oo kaydi feylkii fiidyaha ee ugu dambeeyay. Kamaradu si toos ah ayay tan u samaynaysaa, marka qaabka Loop uu shido.
Adeegga OEM/ODM camera
Waxaan kuu samayn karnaa OEM/ODM Camera oo wata calaamad gaar ah,sumadda,buug-gacmeedka,sanduuqa baakadaha ama guryaha.
1. Logo
- Fadlan noo soo bandhig summadaada xallinta sare oo qaab AI ama cdr ah;
- MOQ ee daabacaadda astaanta waa 100pcs
- Qiimaha daabacadu wuxuu la xiriiraa midabada ,sida caadiga ah waa in aysan jirin wax saameyn ah oo ku jira astaanta
2. Summada
- Fadlan na sii nambaradaada moodeelka ah iyo shuruudaha qaraabo.
3. Buugga
- Fadlan na sii faylka naqshadaynta gacanta ee dhammaatay oo si toos ah loo daabici karo,luqad kasta waa OK , Waxaan sidoo kale bixin karnaa daabacaadda gacanta ee luqadaha badan.
4. Sanduuqa Xirmada
- Waxaan ku siin doonaa demension iyo faylka naqshadeynta;
- Fadlan qaabayso qaab adiga kuu gaar ah oo ku salaysan faylkan ka dibna nagu soo celi;
- Waxaan kuu soo diri doonaa sanduuqa baakadaha xaqiijintaada ka hor wax soo saarka ;
5. Guriyeynta
- Haddii aad rabto in aad samaysato gaadhiga naqshadaynta kiis dvr ,fadlan noo soo bandhig faylka naqshadeynta guryaha , waxaanu furi doonaa caaryada waxaanu ku siin doonaa muunad marka hore.
